Audi TT 2003–2006

1 generation (8N) [restyling]
No photos yet1.8 T AT (180 hp)
General information
Number of doors2
CountryGermany
Steering wheel positionLeft/Right
Car classS
At a glance
Engine1781 cm3 Gasoline
Power180 hp
GearboxAutomatic
OriginGermany
Series
Cabriolet RoadsterCoupe
Trim
1.8 AT (150 PS)1.8 AT (163 PS)1.8 AT (190 PS)1.8 AT (225 hp)1.8 MT (163 PS)1.8 MT (190 PS)1.8 T AT (180 hp)1.8 T MT (150 PS)1.8 T MT (180 hp)1.8 T quattro MT (180 hp)1.8 T quattro MT (225 hp)1.8 T quattro MT (240 hp)3.2 quattro MT (250 PS)3.2 quattro S tronic (250 PS)

Specifications

Engine
Max power (kW)132 kW
Capacity1781 cm3
Engine power179 PS
Engine power180 hp
Turnover of maximum torque1950 RPM
Maximum torque235 N*m
Number of cylinders4
Valves per cylinder5
Max power at RPM5500 RPM
Cylinder bore81 mm
Stroke cycle86.4 mm
Compression ratio9.5
Engine codeAJL
Engine modelAJL
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typeTurbocharged
Bodywork
Ground clearance130 mm
Clearance130 mm
Curb weight1340 kg
Height1346 mm
Rear track1513 mm
Back track width1513 mm
Front track1528 mm
Front track width1528 mm
Full weight1710 kg
Width1764 mm
Wheel size205/55 R16, 225/45 R17
Wheelbase2422 mm
Min trunk capacity270 l
Number of seater4
Length4041 mm
Max trunk capacity540 l
Body typeCoupe
Pitch Circle DiameterDIA57.1 5x100 mm
Gearbox and handling
Turning circle10.6 m
Number of gear6
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
City driving fuel consumption per 100 km11.1 l
Max speed222 km/h
CO2 emissions226 g/km
Fuel tank capacity55 l
Highway driving fuel consumption per 100 km6.3 l
Mixed driving fuel consumption per 100 km8.1 l
Acceleration (0-100 km/h)8.5 s
Fuel95
Emission standardsEuro 3
Cruising rangefrom 420 to 810 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
