Audi A1 2010–2015

1 generation (8X)

No photos yet1.2 MT (86 PS)

General information

Number of doors3

Car classB

CountryGermany

Steering wheel positionLeft/Right

At a glance

Engine1197 cm3 Gasoline

Power84 hp

GearboxManual

Origin

Germany

Series

Quattro hatchback 3-doors Sportback hatchback 5-doors

Trim

1.2 MT (86 PS)1.4 AMT (140 PS)1.4 AMT (185 PS)1.4 MT (140 PS)1.6 AMT (90 PS)1.6 MT (105 PS)1.6 MT (90 PS)2.0 MT (143 PS)2.0 TFSI quattro MT (256 PS)

Specifications

Engine

Compression ratio10

Capacity1197 cm3

Maximum torque160 N*m

Valves per cylinder2

Turnover of maximum torque3500 RPM

Number of cylinders4

Max power at RPM5000 RPM

Max power (kW)63 kW

Cylinder bore71.0 mm

Stroke cycle75.6 mm

Engine power84 hp

Engine power86 PS

Engine codeCBZA

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Curb weight1040 kg

Clearance130 mm

Height1416 mm

Back track width1471 mm

Front track width1477 mm

Full weight1490 kg

Width1740 mm

Wheel size215/45 R16, 205/55 R15, 215/40 R17, 185/60 R15

Wheelbase2469 mm

Min trunk capacity270 l

Length3954 mm

Number of seater4

Max trunk capacity920 l

Pitch Circle DiameterDIA57.1 5x100 mm

Body typeHatchback

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Acceleration (0-100 km/h)11.7 s

CO2 emissions118 g/km

Max speed180 km/h

Highway driving fuel consumption per 100 km4.4 l

Fuel tank capacity45 l

Mixed driving fuel consumption per 100 km5.1 l

City driving fuel consumption per 100 km6.2 l

Fuel95

Emission standardsEuro 5

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc
