Mazda 5 2010–2018
CWNo photos yet1.6 MZ-CD MT (115 hp)
General information
Number of doors5
CountryJapan
Steering wheel positionLeft
Car classM
At a glance
Engine1560 cm3 Diesel
Power115 hp
GearboxManual
Origin
Japan
JapanSpecifications
Engine
Engine power115 hp
Engine power117 PS
Capacity1560 cm3
Compression ratio16
Engine code1.6 MZR-CD
Turnover of maximum torque1750 RPM
Valves per cylinder2
Maximum torque270 N*m
Number of cylinders4
Cylinder bore75 mm
Max power (kW)86 kW
Stroke cycle88.3 mm
Injection typeCommon rail (diesel)
Engine typeDiesel
Max power at RPMfrom 3 600 to 4 000 RPM
Engine placementFront, transverse
Cylinder layoutinline
Engine modelmzr-cd
Presence of intercoolerPresent
Timing beltSOHC
Boost typeTurbocharged
Bodywork
Front/rear axle load1020/1205 kg
Ground clearance130 mm
Clearance130 mm
Curb weight1490 kg
Rear track1520 mm
Back track width1520 mm
Front track1530 mm
Front track width1530 mm
Height1615 mm
Width1750 mm
Wheel size195/65 R15
Full weight2125 kg
Wheelbase2750 mm
Trailer load (with brakes)3475 kg
Min trunk capacity426 l
Length4585 mm
Payload635 kg
Number of seater7
Max trunk capacity780 l
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeMinivan
Gearbox and handling
Turning circle11.2 m
Number of gear6
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)13.7 s
Max speed179 km/h
Highway driving fuel consumption per 100 km4.6 l
Mixed driving fuel consumption per 100 km5.2 l
Fuel tank capacity60 l
City driving fuel consumption per 100 km6.4 l
Fueldiesel
Emission standardsEuro 5
Cruising rangefrom 940 to 1 300 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
No grades recorded for this trim yet.
