Mazda 5 2005–2007

No photos yet1.8 MT (116 hp)

At a glance

Engine1798 cm3 Gasoline

Power116 hp

GearboxManual

OriginN/A

Trim

1.8 MT (115 hp)1.8 MT (116 hp)2.0 AT (145 PS)2.0 AT (146 hp)2.0 MT (145 PS)2.0 MT (146 hp)2.0 MZR-CD MT (110 PS)2.0 MZR-CD MT (143 PS)2.3 AT (153 hp)2.3 AT (155 hp)2.3 AT (159 hp)2.3 MT (153 hp)2.3 MT (155 hp)2.3 MT (159 hp)

Specifications

Engine

Engine power116 hp

Engine power118 PS

Maximum torque165 N*m

Capacity1798 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore83 mm

Stroke cycle83.1 mm

Max power (kW)87 kW

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 000 RPM

Max power at RPMto 5 300 RPM

Bodywork

Ground clearance140 mm

Curb weight1470 kg

Rear track1520 mm

Front track1530 mm

Height1615 mm

Max trunk capacity1678 l

Width1755 mm

Full weight2090 kg

Wheelbase2750 mm

Trailer load (with brakes)3390 kg

Length4505 mm

Number of seater5

Payload620 kg

Min trunk capacity969 l

Body typeMinivan

Gearbox and handling

Turning circle11.2 m

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

City driving fuel consumption per 100 km10.7 l

Acceleration (0-100 km/h)11.4 s

Max speed182 km/h

Fuel tank capacity60 l

Highway driving fuel consumption per 100 km6.3 l

Mixed driving fuel consumption per 100 km7.9 l

Fuel95

Emission standardsEURO IV

Cruising rangefrom 560 to 950 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts, spring

Back suspensionIndependent, Multi wishbone, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
