Mazda 5 2007–2010
CR [restyling]No photos yet1.8 MT (115 hp)
General information
Number of doors5
CountryJapan
Steering wheel positionLeft
Car classM
At a glance
Engine1798 cm3 Gasoline
Power115 hp
GearboxManual
Origin
Japan
JapanSpecifications
Engine
Compression ratio10.8
Engine power115 hp
Engine power116 PS
Maximum torque165 N*m
Capacity1798 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM5300 RPM
Cylinder bore83.0 mm
Stroke cycle83.1 mm
Max power (kW)85 kW
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Engine codeL8-DE
Engine modelmzr
Boost typenone
Bodywork
Ground clearance140 mm
Clearance140 mm
Curb weight1400 kg
Rear track1520 mm
Back track width1520 mm
Front track1530 mm
Front track width1530 mm
Height1615 mm
Max trunk capacity1678 l
Width1755 mm
Wheel size195/65 R15, 205/55 R16
Full weight2110 kg
Wheelbase2750 mm
Trailer load (with brakes)3410 kg
Length4505 mm
Min trunk capacity538 l
Number of seater5, 7
Payload735 kg
Front/rear axle load960/1150 kg
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeMinivan
Gearbox and handling
Turning circle11.2 m
Number of gear5
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
City driving fuel consumption per 100 km10.1 l
Acceleration (0-100 km/h)11.3 s
CO2 emissions179 g/km
Max speed182 km/h
Fuel tank capacity60 l
Highway driving fuel consumption per 100 km6.0 l
Mixed driving fuel consumption per 100 km7.5 l
Fuel95
Emission standardsEuro 4
Cruising rangefrom 590 to 980 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
