Mazda 616 1970–1978

1 generation

No photos yet1.6 MT (74 hp)

At a glance

Engine1586 cm3 Gasoline

Power74 hp

GearboxManual

OriginN/A

Series

Coupe Sedan

Trim

1.6 MT (74 hp)1.6 MT (75 hp)1.6 MT RWD (75 PS)

Specifications

Engine

Maximum torque116 N*m

Capacity1586 cm3

Valves per cylinder2

Number of cylinders4

Max power (kW)55 kW

Engine power74 hp

Engine power75 PS

Cylinder bore78 mm

Stroke cycle83 mm

Injection typecarburetor

Max power at RPMfrom 5 000 RPM

Engine typeGasoline

Cylinder layoutInline

Turnover of maximum torqueto 3 500 RPM

Bodywork

Front track1290 mm

Rear track1290 mm

Height1405 mm

Width1580 mm

Wheelbase2470 mm

Length4260 mm

Number of seater5

Curb weight965 kg

Body typeSedan

Gearbox and handling

Number of gear4

Turning circle9.4 m

Gearbox typeManual

Drive wheelsRear wheel drive

Operating characteristics

Acceleration (0-100 km/h)14.1 s

Max speed152 km/h

Fuel tank capacity50 l

Fuel92

Suspension and brakes

Front brakesdrum

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSpring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
