Mercedes-Benz SL-Class 1963–1971

W113

No photos yet2.3 MT (150 PS)

General information

Number of doors2

CountryGermany

Steering wheel positionLeft

Car classS

At a glance

Engine2306 cm3 Gasoline

Power148 hp

GearboxManual

Origin

Germany

Trim

2.3 AT (150 PS)2.3 MT (150 PS)2.5 AT (150 PS)2.5 MT (150 PS)2.8 AT (170 PS)2.8 MT (170 PS)

Specifications

Engine

Max power (kW)110 kW

Engine power148 hp

Engine power150 PS

Maximum torque196 N*m

Valves per cylinder2

Capacity2306 cm3

Turnover of maximum torque4200 RPM

Max power at RPM5500 RPM

Number of cylinders6

Stroke cycle72.8 mm

Cylinder bore82.0 mm

Compression ratio9.3

Injection typeCentral injection (single-point or single-point)

Engine modelDaimler-Benz M 127

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Engine codeM127.981

Boost typenone

Timing beltSOHC

Bodywork

Clearance125 mm

Curb weight1295 kg

Height1320 mm

Front track width1486 mm

Back track width1487 mm

Full weight1650 kg

Width1760 mm

Wheel size205/65 R15, 205/70 R14

Number of seater2, 4

Wheelbase2400 mm

Min trunk capacity340 l

Length4285 mm

Disc size6.5x14 ET30, 7.5x16 ET25, 7x15 ET25

Pitch Circle DiameterDIA66.6 5x112 mm

Body typeRoadster

Gearbox and handling

Number of gear5

Gearbox typeManual

Drive wheelsRear wheel drive

Operating characteristics

Highway driving fuel consumption per 100 km10.6 l

Mixed driving fuel consumption per 100 km11.2 l

City driving fuel consumption per 100 km13.0 l

Max speed200 km/h

Fuel tank capacity65 l

Acceleration (0-100 km/h)9.7 s

Suspension and brakes

Front brakesDisc

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring
