Mitsubishi Legnum 1996–2002

1 generation (EA1W / EA3W / EA4W / EA5W / EA7W / EC1W / EC3W / EC5W / EC7W)
General information
Number of doors5
Car classD
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1834 cm3 Gasoline
Power148 hp
GearboxAutomatic
OriginJapan
Trim
1.8 AT (150 PS)1.8 MT (150 PS)2.0 AT (145 PS)2.0 AT 4WD (145 hp)2.0 MT (145 PS)2.0 MT 4WD (145 hp)2.4 AT (165 PS)2.4 AT 4WD (165 hp)2.5 AT (175 PS)2.5 AT (200 PS)2.5 AT (280 PS)2.5 AT 4WD (175 hp)2.5 AT VR-4 type S 4WD (260 hp)2.5 MT (175 PS)2.5 MT (200 PS)2.5 MT 4WD (175 hp)2.5 MT VR-4 4WD (280 PS)

Specifications

Engine
Max power (kW)110 kW
Compression ratio12
Engine power148 hp
Engine power150 PS
Maximum torque179 N*m
Capacity1834 cm3
Number of cylinders4
Valves per cylinder4
Engine code4G93 GDI
Turnover of maximum torque5000 RPM
Max power at RPM5500 RPM
Cylinder bore81 mm
Stroke cycle89 mm
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1330 kg
Ground clearance140 mm
Clearance140 mm
Height1470 mm
Rear track1505 mm
Back track width1505 mm
Front track1510 mm
Front track width1510 mm
Width1740 mm
Full weight1825 kg
Wheel size185/70 R14, 195/60 R15
Wheelbase2635 mm
Length4700 mm
Number of seater5
Pitch Circle DiameterDIA67.1 4x114.3 mm
Body typeWagon
Gearbox and handling
Turning circle10.8 m
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Mixed driving fuel consumption per 100 km10.2 l
City driving fuel consumption per 100 km11.9 l
Acceleration (0-100 km/h)13.0 s
Fuel tank capacity60 l
Highway driving fuel consumption per 100 km7.8 l
Fuel95
Suspension and brakes
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
