Suzuki Escudo 1994–1997

1 generation (TA01W / TA01R / TD01W / TD01R) [restyling]

At a glance

Engine1590 cm3 Gasoline

Power100 hp

GearboxAutomatic

OriginN/A

Series

SUV SUV 3-doors

Trim

1.6 AT (100 hp)1.6 MT (100 hp)2.0 AT (140 hp)2.0D MT (76 hp)2.0 MT (140 hp)2.0 V6 AT (145 hp)2.0 V6 MT (145 hp)

Specifications

Engine

Engine power100 hp

Engine power102 PS

Maximum torque137 N*m

Capacity1590 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore75 mm

Max power (kW)75 kW

Stroke cycle90 mm

Engine typeGasoline

Injection typeInjector

Cylinder layoutInline

Turnover of maximum torqueto 4 500 RPM

Max power at RPMto 6 000 RPM

Bodywork

Curb weight1140 kg

Front track1395 mm

Rear track1400 mm

Width1665 mm

Height1705 mm

Ground clearance200 mm

Wheelbase2200 mm

Length3670 mm

Number of seater5

Body typeCrossover

Gearbox and handling

Number of gear4

Turning circle9.8 m

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Fuel tank capacity42 l

Mixed driving fuel consumption per 100 km8.6 l

Fuel92

Suspension and brakes

Front brakesDisc

Rear brakesdrum

Front suspensionStrut, Stabilizer bar

Back suspensionWishbone, Stabilizer bar

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
