Toyota Blade 2009–2012

1 generation [restyling]

General information

Number of doors5

Car classC

CountryJapan

Steering wheel positionRight

At a glance

Engine2362 cm3 Gasoline

Power165 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

2.4 CVT (167 PS)2.4 CVT 4WD (167 hp)3.5 AT (280 PS)

Specifications

Engine

Max power (kW)123 kW

Engine power165 hp

Engine power167 PS

Maximum torque224 N*m

Capacity2362 cm3

Engine model2az-fe

Engine code2AZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM6000 RPM

Cylinder bore88.5 mm

Compression ratio9.6

Stroke cycle96.0 mm

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Ground clearance135 mm

Clearance140 mm

Curb weight1450 kg

Height1515 mm

Rear track1520 mm

Back track width1520 mm

Front track1525 mm

Front track width1525 mm

Width1760 mm

Wheelbase2600 mm

Length4260 mm

Number of seater5

Body typeHatchback

Gearbox and handling

Turning circle10.4 m

Drive wheelsAll wheel drive (AWD)

Gearbox typeContinuously variable transmission (CVT)

Operating characteristics

Fuel tank capacity60 l

Mixed driving fuel consumption per 100 km7.8 l

Fuel95

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
