Toyota FJ Cruiser 2006–2010
1 generation (J15)At a glance
Engine3956 cm3 Gasoline
Power242 hp
GearboxAutomatic
OriginN/A
Specifications
Engine
Max power (kW)180 kW
Engine power242 hp
Engine power245 PS
Maximum torque377 N*m
Capacity3956 cm3
Valves per cylinder4
Number of cylinders6
Cylinder bore94 mm
Stroke cycle95 mm
Engine typeGasoline
Injection typeMulti-point fuel injection
Turnover of maximum torqueto 3 700 RPM
Max power at RPMto 5 200 RPM
Cylinder layoutV-type
Bodywork
Front track1605 mm
Rear track1605 mm
Height1819 mm
Max trunk capacity1892 l
Width1895 mm
Curb weight1948 kg
Ground clearance244 mm
Full weight2549 kg
Wheelbase2690 mm
Length4671 mm
Trailer load (with brakes)4817 kg
Number of seater5
Payload601 kg
Min trunk capacity790 l
Body typeCrossover
Gearbox and handling
Turning circle12.4 m
Number of gear5
Gearbox typeAutomatic
Drive wheelsFour wheel drive (4WD)
Operating characteristics
Highway driving fuel consumption per 100 km12.3 l
Mixed driving fuel consumption per 100 km13.8 l
City driving fuel consumption per 100 km15.6 l
Fuel tank capacity72 l
Fuel95
Emission standardsEURO IV
Cruising rangefrom 460 to 590 km
Suspension and brakes
Front suspensionIndependent, Double wishbone, Stabilizer bar
Back suspensionIndependent, Multi wishbone, spring, Stabilizer bar
Front brakesventilated disc
Rear brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
No grades recorded for this trim yet.
