Toyota Harrier 1997–2000

1 generation (XU10)
General information
Number of doors5
Car classE
CountryJapan
Steering wheel positionRight
At a glance
Engine2164 cm3 Gasoline
Power138 hp
GearboxAutomatic
OriginJapan
Trim
2.2 AT (140 PS)2.2 AT 4WD (140 hp)2.4 AT (160 PS)2.4 AT 4WD (160 hp)3.0 AT (220 PS)3.0 AT 4WD (220 hp)

Specifications

Engine
Max power (kW)103 kW
Engine power138 hp
Engine power140 PS
Maximum torque191 N*m
Capacity2164 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4400 RPM
Max power at RPM5600 RPM
Engine model5s-fe
Engine code5S-FE
Cylinder bore87.0 mm
Stroke cycle91.0 mm
Compression ratio9.8
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Rear track1550 mm
Back track width1550 mm
Front track1565 mm
Front track width1565 mm
Height1665 mm
Curb weight1680 kg
Width1815 mm
Ground clearance185 mm
Clearance185 mm
Max trunk capacity2130 l
Wheel size215/70 R16
Wheelbase2615 mm
Length4575 mm
Number of seater5
Min trunk capacity860 l
Body typeCrossover
Pitch Circle DiameterDIA60.1 5x114.3 mm
Gearbox and handling
Turning circle11.4 m
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
City driving fuel consumption per 100 km10 l
Mixed driving fuel consumption per 100 km10.9 l
Acceleration (0-100 km/h)12.4 s
Max speed170 km/h
Highway driving fuel consumption per 100 km6.1 l
Fuel tank capacity65 l
Fuel92
Cruising rangefrom 650 to 1 070 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
