Toyota Hiace 1982–1989

H50 H60 H70

General information

Number of doors4

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine1812 cm3 Gasoline

Power94 hp

GearboxManual

Origin

Japan

Series

Minivan Van

Trim

1.8 MT (95 PS)2.0 AT (105 PS)2.0 AT 4WD (105 PS)2.0 AT (98 PS)2.0 MT (105 PS)2.0 MT 4WD (105 PS)2.0 MT (98 PS)2.2 MT 4WD (72 PS)2.2 MT (72 PS)2.5 AT (75 PS)2.5 MT 4WD (75 PS)2.8 MT (83 PS)

Specifications

Engine

Maximum torque152 N*m

Capacity1812 cm3

Valves per cylinder2

Engine code2Y

Engine model2Y

Turnover of maximum torque3400 RPM

Number of cylinders4

Max power at RPM5200 RPM

Max power (kW)70 kW

Stroke cycle78.0 mm

Cylinder bore86.0 mm

Compression ratio8.8

Engine power94 hp

Engine power95 PS

Injection typecarburetor

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltOHV

Bodywork

Curb weight1355 kg

Back track width1400 mm

Front track width1440 mm

Width1690 mm

Height1950 mm

Wheel size195/75 R14, 205/70 R14

Clearance200 mm

Wheelbase2495 mm

Full weight2520 kg

Length4690 mm

Disc size5.5x14 ET35

Number of seater6, 8

Pitch Circle DiameterDIA67.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Number of gear4

Gearbox typeManual

Drive wheelsRear wheel drive

Operating characteristics

Fuel tank capacity60 l

Fuel76

Suspension and brakes

Back suspensionDependent, spring

Front brakesdrum

Rear brakesdrum

Front suspensionIndependent, spring

Grades & features
