Toyota Lite Ace 1979–1985

2 generation (M20)

No photos yet1.8 MT (92 PS)

General information

Number of doors4

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine1770 cm3 Gasoline

Power91 hp

GearboxManual

Origin

Japan

Series

Minivan Van

Trim

1.3 MT (69 PS)1.8 MT (79 PS)1.8 MT (92 PS)1.8 MT (95 PS)

Specifications

Engine

Engine code13T-U

Engine model13T-U

Maximum torque147 N*m

Capacity1770 cm3

Valves per cylinder2

Turnover of maximum torque3400 RPM

Number of cylinders4

Max power at RPM5000 RPM

Max power (kW)68 kW

Stroke cycle78 mm

Cylinder bore85 mm

Compression ratio8.6

Engine power91 hp

Engine power92 PS

Injection typecarburetor

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltOHV

Bodywork

Curb weight1120 kg

Back track width1345 mm

Front track width1350 mm

Clearance160 mm

Width1625 mm

Wheel size165/80 R13

Height1750 mm

Wheelbase2080 mm

Length3900 mm

Disc size4.5x13 ET35

Number of seater8

Pitch Circle DiameterDIA60.1 4x114.3 mm

Body typeMinivan

Gearbox and handling

Number of gear4

Gearbox typeManual

Drive wheelsRear wheel drive

Operating characteristics

Acceleration (0-100 km/h)14.4 s

Fuel tank capacity48 l

Fuel92

Suspension and brakes

Back suspensionDependent, spring

Front brakesDisc

Rear brakesdrum

Front suspensionIndependent, Torsion

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
