Toyota Matrix 2008–2014

2 generation
No photos yet2.4 AT (158 PS)
General information
Number of doors5
CountryJapan
Steering wheel positionLeft
Car classM
At a glance
Engine2362 cm3 Gasoline
Power156 hp
GearboxAutomatic
OriginJapan
Series
Hatchback 5-doorsXR hatchback 5-doorsXRS hatchback 5-doors
Trim
1.8 AT (132 PS)1.8 MT (132 PS)2.4 AT (158 PS)2.4 MT (158 PS)

Specifications

Engine
Max power (kW)116 kW
Engine power156 hp
Engine power158 PS
Maximum torque225 N*m
Capacity2362 cm3
Engine code2AZ-FE
Engine model2az-fe i4
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM5600 RPM
Cylinder bore88.5 mm
Stroke cycle96 mm
Compression ratio9.6
Injection typedistributed injection (multipoint)
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Timing beltOHC
Bodywork
Ground clearance135 mm
Clearance135 mm
Curb weight1485 kg
Front track1519 mm
Front track width1519 mm
Back track width1521 mm
Rear track1522 mm
Height1549 mm
Max trunk capacity1562 l
Width1765 mm
Wheel size215/45 R18
Wheelbase2601 mm
Length4366 mm
Number of seater5
Min trunk capacity502 l
Pitch Circle DiameterDIA60.1 5x114.3 mm
Body typeHatchback
Gearbox and handling
Turning circle11 m
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
City driving fuel consumption per 100 km10.2 l
Fuel tank capacity50 l
Highway driving fuel consumption per 100 km7.4 l
Mixed driving fuel consumption per 100 km9.1 l
Fuel95
Cruising rangefrom 510 to 710 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
