Toyota Ractis 2010–2016
2 generationNo photos yet1.3 CVT (99 hp)
At a glance
Engine1329 cm3 Gasoline
Power99 hp
GearboxContinuously variable transmission (CVT)
OriginN/A
Series
Specifications
Engine
Engine power101 PS
Maximum torque125 N*m
Capacity1329 cm3
Number of cylinders4
Valves per cylinder4
Cylinder bore72.5 mm
Max power (kW)74 kW
Stroke cycle80.5 mm
Engine power99 hp
Engine typeGasoline
Cylinder layoutInline
Injection typeMulti-point fuel injection
Turnover of maximum torqueto 4 000 RPM
Max power at RPMto 6 000 RPM
Bodywork
Curb weight1075 kg
Max trunk capacity1353 l
Ground clearance145 mm
Rear track1465 mm
Front track1470 mm
Full weight1550 kg
Height1595 mm
Width1695 mm
Trailer load (with brakes)2350 kg
Wheelbase2550 mm
Min trunk capacity395 l
Length3990 mm
Payload475 kg
Number of seater5
Body typeMinivan
Gearbox and handling
Turning circle11.4 m
Gearbox typeContinuously variable transmission (CVT)
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)13.7 s
Max speed165 km/h
Highway driving fuel consumption per 100 km3.8 l
Fuel tank capacity42 l
Mixed driving fuel consumption per 100 km4.3 l
City driving fuel consumption per 100 km5.1 l
Fuel95
Emission standardsEURO V
Cruising rangefrom 820 to 1 110 km
Suspension and brakes
Rear brakesdrum
Front suspensionIndependent, McPherson Struts, Dampers, spring, Stabilizer bar
Back suspensionTorsion beam, spring
Front brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
No grades recorded for this trim yet.
