Toyota Ractis 2005–2007

1 generation

No photos yet1.3 CVT (87 hp)

At a glance

Engine1296 cm3 Gasoline

Power87 hp

GearboxContinuously variable transmission (CVT)

OriginN/A

Trim

1.3 CVT (87 hp)1.5 AT AWD (105 hp)1.5 CVT (110 hp)

Specifications

Engine

Maximum torque116 N*m

Capacity1296 cm3

Number of cylinders4

Valves per cylinder4

Max power (kW)65 kW

Cylinder bore72 mm

Stroke cycle79.6 mm

Engine power87 hp

Engine power88 PS

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 000 RPM

Max power at RPMto 6 000 RPM

Bodywork

Curb weight1120 kg

Rear track1475 mm

Front track1485 mm

Ground clearance155 mm

Height1640 mm

Width1695 mm

Wheelbase2550 mm

Length3955 mm

Number of seater5

Body typeMinivan

Gearbox and handling

Turning circle9.8 m

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

Fuel tank capacity42 l

Mixed driving fuel consumption per 100 km5.4 l

Fuel95

Suspension and brakes

Rear brakesdrum

Front suspensionMcPherson Struts, spring, Stabilizer bar

Back suspensionTorsion beam, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
