Toyota Raum 2003–2011

2 generation

No photos yet1.5 AT 4WD (105 PS)

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine1497 cm3 Gasoline

Power103 hp

GearboxAutomatic

Origin

Japan

Trim

1.5 AT 4WD (105 PS)1.5 AT 4WD (109 PS)

Specifications

Engine

Engine power103 hp

Engine power105 PS

Compression ratio10.5

Maximum torque138 N*m

Capacity1497 cm3

Engine code1NZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4200 RPM

Engine model5a-fe

Max power at RPM6000 RPM

Cylinder bore75.0 mm

Max power (kW)77 kW

Stroke cycle84.7 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1220 kg

Clearance140 mm

Rear track1420 mm

Back track width1430 mm

Front track1450 mm

Front track width1455 mm

Ground clearance150 mm

Height1535 mm

Width1690 mm

Wheel size175/65 R14

Wheelbase2500 mm

Length4045 mm

Number of seater5

Pitch Circle DiameterDIA54.1 4x100 mm

Body typeMinivan

Gearbox and handling

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

City driving fuel consumption per 100 km11 l

Acceleration (0-100 km/h)11.5 s

Max speed170 km/h

Fuel tank capacity45 l

Mixed driving fuel consumption per 100 km6.6 l

Highway driving fuel consumption per 100 km7 l

Fuel92

Cruising rangefrom 410 to 640 km

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
