Toyota Sprinter Trueno 1983–1987

4 generation (AE85/AE86)
No photos yet1.5 MT (85 hp)
General information
Number of doors2
Car classC
CountryJapan
Steering wheel positionRight
At a glance
Engine1452 cm3 Gasoline
Power85 hp
GearboxManual
OriginJapan
Series
CoupeHatchback 3 doors
Trim
1.5 AT (85 hp)1.5 MT (85 hp)1.6 AT (130 hp)1.6 MT (130 hp)

Specifications

Engine
Maximum torque118 N*m
Capacity1452 cm3
Valves per cylinder2
Turnover of maximum torque3600 RPM
Engine model3a-u
Engine code3A-U
Number of cylinders4
Max power at RPM5600 RPM
Max power (kW)63 kW
Stroke cycle77 mm
Cylinder bore77.5 mm
Engine power85 hp
Engine power86 PS
Compression ratio9.3
Injection typecarburetor
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Timing beltOHC
Bodywork
Height1335 mm
Back track width1345 mm
Front track width1355 mm
Clearance155 mm
Wheel size155/80 R13
Width1625 mm
Wheelbase2400 mm
Length4205 mm
Number of seater5
Disc size5x13 ET27
Curb weight915 kg
Body typeCoupe
Pitch Circle DiameterDIA54.1 4x100 mm
Gearbox and handling
Number of gear5
Gearbox typeManual
Drive wheelsRear wheel drive
Operating characteristics
Acceleration (0-100 km/h)12.6 s
Fuel tank capacity50 l
Mixed driving fuel consumption per 100 km5.9 l
Suspension and brakes
Front brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
