BMW Z1 1988–1991

E30/Z
No photos yet2.5 MT (170 hp)
General information
Number of doors2
CountryGermany
Steering wheel positionLeft
Car classS
At a glance
Engine2494 cm3 Gasoline
Power170 hp
GearboxManual
OriginGermany
Trim
2.5 MT (170 hp)2.5 MT RWD (170 PS)

Specifications

Engine
Max power (kW)127 kW
Engine power170 hp
Engine power173 PS
Valves per cylinder2
Maximum torque222 N*m
Capacity2494 cm3
Turnover of maximum torque4300 RPM
Number of cylinders6
Stroke cycle75.0 mm
Cylinder bore84.0 mm
Compression ratio8.5
Injection typedistributed injection (multipoint)
Engine placementFront, longitudinal
Engine typeGasoline
Cylinder layoutinline
Engine modelm20b25
Engine codeM20B25
Boost typenone
Timing beltSOHC
Max power at RPMto 5 800 RPM
Bodywork
Clearance120 mm
Curb weight1250 kg
Height1277 mm
Front track1456 mm
Front track width1456 mm
Full weight1460 kg
Rear track1470 mm
Back track width1470 mm
Width1690 mm
Number of seater2
Payload210 kg
Wheelbase2447 mm
Min trunk capacity260 l
Max trunk capacity260 l
Length3921 mm
Front/rear axle load665/820 kg
Body typeRoadster
Gearbox and handling
Turning circle10.3 m
Number of gear5
Gearbox typeManual
Drive wheelsRear wheel drive
Operating characteristics
City driving fuel consumption per 100 km12.9 l
Max speed225 km/h
Fuel tank capacity55 l
Highway driving fuel consumption per 100 km6.8 l
Acceleration (0-100 km/h)7.9 s
Fuel92
Mixed driving fuel consumption per 100 km9.4 l
Cruising rangefrom 430 to 810 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
