BYD L3 2010–2015

1 generation

No photos yet1.5 MT (105 PS)

General information

Number of doors4

Car classC

CountryChina

Steering wheel positionLeft

At a glance

Engine1497 cm3 Gasoline

Power103 hp

GearboxManual

Origin

China

Trim

1.5 MT (105 PS)1.8 CVT (121 PS)1.8 MT (121 PS)

Specifications

Engine

Engine power103 hp

Compression ratio10.3

Engine power105 PS

Maximum torque145 N*m

Capacity1497 cm3

Number of cylinders4

Valves per cylinder4

Engine code473QE

Turnover of maximum torque4800 RPM

Max power at RPM5800 RPM

Cylinder bore73.0 mm

Max power (kW)77 kW

Stroke cycle89.4 mm

Engine modelbyd473qe

Injection typedistributed injection (multipoint)

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltSOHC

Bodywork

Curb weight1180 kg

Back track width1466 mm

Height1480 mm

Front track width1486 mm

Clearance170 mm

Width1716 mm

Wheel size195/60/R15

Wheelbase2615 mm

Length4568 mm

Number of seater5

Body typeSedan

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Max speed170 km/h

Mixed driving fuel consumption per 100 km7.5 l

Fuel92

Suspension and brakes

Front brakesDisc

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionSemi-independent, torsion
