Cadillac XTS 2012–2017

1 generation

No photos yet3.6 AT 4WD (325 PS)

General information

Number of doors4

Car classF

Steering wheel positionLeft

CountryUSA

At a glance

Engine3564 cm3 Gasoline

Power321 hp

GearboxAutomatic

Origin

United States

Trim

3.6 AT 4WD (325 PS)3.6 AT 4WD (410 hp)

Specifications

Engine

Compression ratio11.4

Max power (kW)239 kW

Engine power321 hp

Engine power325 PS

Capacity3564 cm3

Maximum torque371 N*m

Valves per cylinder4

Turnover of maximum torque4800 RPM

Number of cylinders6

Max power at RPM6800 RPM

Stroke cycle85.6 mm

Cylinder bore94.0 mm

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Engine codeLFX

Boost typenone

Cylinder layoutV-type

Bodywork

Clearance130 mm

Height1510 mm

Front track width1582 mm

Back track width1587 mm

Width1852 mm

Curb weight1896 kg

Wheelbase2837 mm

Number of seater5

Min trunk capacity509 l

Length5131 mm

Body typeSedan

Gearbox and handling

Number of gear6

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Mixed driving fuel consumption per 100 km11.1 l

City driving fuel consumption per 100 km13.8 l

Max speed250 km/h

Acceleration (0-100 km/h)6.9 s

Fuel tank capacity70 l

Highway driving fuel consumption per 100 km8.7 l

Fuel95

Suspension and brakes

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
