Chery Tiggo 7 2020–2024

2 generation

No photos yet1.5 MT (156 PS)

General information

Number of doors5

Car classC

CountryChina

Steering wheel positionLeft

At a glance

Engine1498 cm3 Gasoline

Power154 hp

GearboxManual

Origin

China

Trim

1.5 AT (340 hp)1.5 CVT (156 PS)1.5 MT (156 PS)1.6 AMT (197 PS)1.6 AMT 4WD (197 PS)

Specifications

Engine

Max power (kW)115 kW

Capacity1498 cm3

Engine power154 hp

Engine power156 PS

Maximum torque230 N*m

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM5500 RPM

Cylinder bore77.0 mm

Stroke cycle80.5 mm

Compression ratio9.5

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Engine modelSQRE4T15C

Engine codeSQRE4T15C

Boost typeTurbocharged

Flow calculation methodWLTP

Bodywork

Curb weight1465 kg

Max trunk capacity1500 l

Front track width1556 mm

Back track width1558 mm

Height1746 mm

Width1842 mm

Full weight1887 kg

Clearance196 mm

Wheel size225/65 R17

Wheelbase2670 mm

Length4500 mm

Min trunk capacity475 l

Number of seater5

Body typeCrossover

Gearbox and handling

Number of gear6

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Max speed188 km/h

CO2 emissions195 g/km

Fuel tank capacity51 l

Mixed driving fuel consumption per 100 km7.5 l

Fuel92

Emission standardsEuro 6

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
