Chery Tiggo 5 2014–2016

T21

No photos yet2.0 MT (136 hp)

At a glance

Engine1971 cm3 Gasoline

Power136 hp

GearboxManual

OriginN/A

Trim

2.0 CVT (136 hp)2.0 CVT (139 PS)2.0 MT (136 hp)2.0 MT (139 PS)

Specifications

Engine

Max power (kW)101 kW

Engine power136 hp

Engine power137 PS

Maximum torque180 N*m

Capacity1971 cm3

Number of cylinders4

Valves per cylinder4

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 500 RPM

Max power at RPMto 5 750 RPM

Bodywork

Curb weight1495 kg

Rear track1510 mm

Front track1530 mm

Ground clearance163 mm

Height1740 mm

Width1841 mm

Wheelbase2610 mm

Min trunk capacity370 l

Max trunk capacity370 l

Length4506 mm

Number of seater5

Body typeCrossover

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Max speed175 km/h

Fuel tank capacity55 l

Mixed driving fuel consumption per 100 km8.5 l

Fuel95

Emission standardsEURO IV

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts, Stabilizer bar

Back suspensionIndependent, Wishbone, Dampers, Stabilizer bar

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
