Chery Tiggo 3x 2020–2026

1 generation [restyling]

No photos yet1.0 CVT (102 PS)

General information

Number of doors5

Car classB

CountryChina

Steering wheel positionLeft

At a glance

Engine998 cm3 Gasoline

Power101 hp

GearboxContinuously variable transmission (CVT)

Origin

China

Trim

1.0 CVT (102 PS)1.5 CVT (116 PS)1.5 MT (116 PS)

Specifications

Engine

Engine power101 hp

Engine power102 PS

Maximum torque150 N*m

Number of cylinders3

Valves per cylinder4

Turnover of maximum torque4500 RPM

Max power at RPM5500 RPM

Cylinder bore71 mm

Max power (kW)75 kW

Stroke cycle84 mm

Compression ratio9.5

Capacity998 cm3

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Engine modelSQRE3T10

Engine codeSQRE3T10

Boost typeTurbocharged

Bodywork

Back track width1484 mm

Front track width1495 mm

Height1570 mm

Width1760 mm

Wheel size205/55 R16

Wheelbase2555 mm

Length4200 mm

Number of seater5

Body typeCrossover

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

Fuel tank capacity48 l

Fuel92

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
