Chevrolet Uplander 2004–2008

1 generation
No photos yet3.9 AT (243 PS)
General information
Number of doors5
Steering wheel positionLeft
Car classM
CountryUSA
At a glance
Engine3880 cm3 Gasoline
Power240 hp
GearboxAutomatic
OriginUnited States
Trim
3.5 Hydra-Matic AWD LWB (196 hp)3.5 Hydra-Matic AWD LWB (200 hp)3.5 Hydra-Matic LWB (200 hp)3.5 Hydra-Matic LWB (201 hp)3.9 AT (243 PS)3.9 Flex-Fuel Hydra-Matic LWB (240 hp)3.9 Flex-Fuel Hydra-Matic SWB (240 hp)3.9 Hydra-Matic LWB (240 hp)3.9 Hydra-Matic SWB (240 hp)

Specifications

Engine
Max power (kW)179 kW
Valves per cylinder2
Engine power240 hp
Engine power243 PS
Maximum torque325 N*m
Capacity3880 cm3
Turnover of maximum torque4800 RPM
Number of cylinders6
Max power at RPM6000 RPM
Stroke cycle84.0 mm
Compression ratio9.8
Cylinder bore99.0 mm
Injection typedistributed injection (multipoint)
Engine placementFront, transverse
Engine typeGasoline
Engine codeLZ9
Engine modelLZ9
Boost typenone
Timing beltOHV
Cylinder layoutV-type
Bodywork
Clearance139 mm
Front track width1586 mm
Back track width1598 mm
Height1790 mm
Width1830 mm
Curb weight1855 kg
Wheel size225/60 R17, 225/60 R18
Full weight2550 kg
Wheelbase2870 mm
Max trunk capacity3401 l
Length4851 mm
Min trunk capacity501 l
Number of seater7
Pitch Circle DiameterDIA71.5 6x115 mm
Body typeMinivan
Gearbox and handling
Number of gear4
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)10.5 s
City driving fuel consumption per 100 km13.1 l
Max speed175 km/h
Fuel tank capacity76 l
Highway driving fuel consumption per 100 km9.4 l
Suspension and brakes
Front brakesDisc
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionSemi-dependent, spring
