Chevrolet Avalanche 2001–2006

1 generation
No photos yet5.3 AT 4WD (295 hp)
General information
Number of doors4
Car classJ
Steering wheel positionLeft
CountryUSA
At a glance
Engine5327 cm3 Gasoline
Power295 hp
GearboxAutomatic
OriginUnited States
Trim
5.3 AT (285 hp)5.3 AT (295 hp)5.3 AT 4WD (285 hp)5.3 AT 4WD (295 hp)8.1 AT (320 hp)8.1 AT (325 PS)8.1 AT (340 hp)8.1 AT 4WD (320 hp)8.1 AT 4WD (340 hp)

Specifications

Engine
Valves per cylinder2
Max power (kW)216 kW
Engine power294 PS
Engine power295 hp
Turnover of maximum torque4000 RPM
Maximum torque441 N*m
Max power at RPM5200 RPM
Capacity5327 cm3
Number of cylinders8
Stroke cycle92 mm
Compression ratio9.5
Cylinder bore96 mm
Injection typedistributed injection (multipoint)
Engine placementFront, longitudinal
Engine typeGasoline
Boost typenone
Timing beltOHV
Engine codeVORTEC 5300
Engine modelvortec 5300 lm7
Cylinder layoutV-type
Bodywork
Min trunk capacity1512 l
Max trunk capacity1526 l
Front track1651 mm
Front track width1651 mm
Rear track1676 mm
Back track width1676 mm
Front/rear axle load1780/1814 kg
Height1869 mm
Width2027 mm
Ground clearance218 mm
Clearance218 mm
Wheel size245/75 R16
Curb weight2576 kg
Full weight3181 kg
Wheelbase3302 mm
Number of seater5
Length5631 mm
Payload600 kg
Loading height787 mm
Pitch Circle DiameterDIA78.1 6x139.7 mm
Body typePickup
Gearbox and handling
Turning circle13.2 m
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Acceleration (0-100 km/h)10.0 s
Fuel tank capacity117 l
Highway driving fuel consumption per 100 km13.1 l
Mixed driving fuel consumption per 100 km14.2 l
City driving fuel consumption per 100 km16.8 l
Max speed180 km/h
Fuel92
Cruising rangefrom 650 to 850 km
Suspension and brakes
Back suspensionDependent, spring
Rear brakesDisc
Front suspensionIndependent, Torsion
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
