Ford Escape 2004–2007

1 generation (U204) [restyling]

At a glance

Engine2294 cm3 Gasoline

Power153 hp

GearboxAutomatic

OriginN/A

Series

Crossover 5-doors Hybrid crossover 5-doors

Trim

2.3 AT (153 hp)2.3 AT (155 PS)2.3 AT 4WD (153 hp)2.3 CVT (157 hp)2.3 MT (153 hp)2.3 MT (155 PS)2.3 MT 4WD (153 hp)3.0 AT (200 hp)3.0 AT (203 PS)3.0 AT 4WD (200 hp)

Specifications

Engine

Max power (kW)114 kW

Engine power153 hp

Engine power155 PS

Maximum torque206 N*m

Capacity2294 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore87.4 mm

Stroke cycle94 mm

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 250 RPM

Max power at RPMto 5 800 RPM

Bodywork

Front/rear axle load1080/1039 kg

Rear track1534 mm

Curb weight1545 kg

Front track1552 mm

Height1770 mm

Width1778 mm

Max trunk capacity1877 l

Full weight2050 kg

Ground clearance208 mm

Wheelbase2621 mm

Trailer load (with brakes)2731 kg

Length4442 mm

Number of seater5

Payload505 kg

Min trunk capacity830 l

Body typeCrossover

Gearbox and handling

Turning circle10.8 m

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Highway driving fuel consumption per 100 km11.8 l

Acceleration (0-100 km/h)13 s

Mixed driving fuel consumption per 100 km13.1 l

City driving fuel consumption per 100 km13.8 l

Max speed177 km/h

Fuel tank capacity62 l

Fuel92

Cruising rangefrom 450 to 530 km

Suspension and brakes

Front brakesDisc

Rear brakesdrum

Front suspensionIndependent, McPherson Struts, spring, Stabilizer bar

Back suspensionIndependent, Multi wishbone, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
