Ford Fusion (North America) 2009–2012

1 generation [restyling]

No photos yet2.5 MT (175 hp)

General information

Number of doors4

Car classD

Steering wheel positionLeft

CountryUSA

At a glance

Engine2488 cm3 Gasoline

Power175 hp

GearboxManual

Origin

United States

Trim

2.5 AT (175 hp)2.5 CVT (191 hp)2.5 MT (175 hp)3.0 AT (240 hp)3.0 AT (250 hp)3.0 AT 4WD (240 hp)3.0 AT 4WD (250 hp)3.5 AT (263 hp)3.5 AT 4WD (263 hp)

Specifications

Engine

Stroke cycle100 mm

Max power (kW)130 kW

Engine power175 hp

Engine power177 PS

Maximum torque233 N*m

Capacity2488 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4500 RPM

Max power at RPM6000 RPM

Cylinder bore89 mm

Compression ratio9.7

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine modelDuratec 25

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Engine codeytma

Bodywork

Clearance132 mm

Height1445 mm

Curb weight1490 kg

Back track width1557 mm

Front track width1567 mm

Width1834 mm

Full weight1990 kg

Wheel size205/60 R16, 225/50 R17

Wheelbase2728 mm

Min trunk capacity467 l

Length4841 mm

Number of seater5

Body typeSedan

Gearbox and handling

Number of gear6

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

City driving fuel consumption per 100 km10.7 l

Max speed180 km/h

Fuel tank capacity66 l

Highway driving fuel consumption per 100 km7.6 l

Acceleration (0-100 km/h)8.8 s

Fuel92

Mixed driving fuel consumption per 100 km9.4 l

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
