GMC Sierra 1998–2007

1 generation (GMT800)

No photos yet4.3 MT 4WD (200 PS)

General information

Number of doors2

Car classJ

Steering wheel positionLeft

CountryUSA

At a glance

Engine4293 cm3 Gasoline

Power197 hp

GearboxManual

Origin

United States

Series

Pickup Double cabin Pickup One-and-a-half cabin Pickup Single cabin

Trim

4.3 AT 4WD (200 PS)4.3 MT 4WD (200 PS)5.3 AT 4WD (288 PS)5.3 MT 4WD (288 PS)

Specifications

Engine

Cylinder bore101.6 mm

Max power (kW)147 kW

Engine power197 hp

Valves per cylinder2

Engine power200 PS

Turnover of maximum torque2800 RPM

Maximum torque353 N*m

Capacity4293 cm3

Max power at RPM4600 RPM

Number of cylinders6

Stroke cycle88.4 mm

Compression ratio9

Injection typedistributed injection (multipoint)

Engine placementFront, longitudinal

Engine typeGasoline

Engine codeLB4

Engine modelLB4

Boost typenone

Timing beltOHV

Cylinder layoutV-type

Bodywork

Height1808 mm

Curb weight1847 kg

Width1994 mm

Number of seater2

Clearance203 mm

Wheel size255/75/R16

Full weight2767 kg

Wheelbase3023 mm

Length5161 mm

Body typePickup

Gearbox and handling

Number of gear5

Drive wheelsAll wheel drive (AWD)

Gearbox typeManual

Operating characteristics

Fuel tank capacity129 l

Fuel95

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
