GMC Terrain 2017–2021

2 generation

No photos yet1.5 AT (170 PS)

General information

Number of doors5

Car classC

Steering wheel positionLeft

CountryUSA

At a glance

Engine1490 cm3 Gasoline

Power168 hp

GearboxAutomatic

Origin

United States

Trim

1.5 AT (170 PS)1.5 AT 4WD (170 PS)1.5 AT 4WD (177 hp)1.5 CVT (177 hp)1.6 AT (137 hp)1.6 AT 4WD (137 hp)2.0 AT (252 hp)2.0 AT 4WD (252 PS)

Specifications

Engine

Compression ratio10

Max power (kW)125 kW

Capacity1490 cm3

Engine power168 hp

Engine power170 PS

Turnover of maximum torque2000 RPM

Maximum torque275 N*m

Number of cylinders4

Valves per cylinder4

Max power at RPM5600 RPM

Cylinder bore74 mm

Stroke cycle86.6 mm

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Engine codeLYX

Engine modelLYX

Boost typeTurbocharged

Bodywork

Front track width1582 mm

Curb weight1582 kg

Back track width1587 mm

Height1661 mm

Clearance175 mm

Max trunk capacity1792 l

Width1839 mm

Full weight2024 kg

Wheel size225/65 R17

Wheelbase2725 mm

Length4630 mm

Number of seater5

Min trunk capacity838 l

Body typeCrossover

Pitch Circle DiameterDIA70.3 5x115 mm

Gearbox and handling

Number of gear9

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Fuel tank capacity56 l

Highway driving fuel consumption per 100 km7.8 l

Mixed driving fuel consumption per 100 km8.4 l

City driving fuel consumption per 100 km9.0 l

Fuel95

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc
