Honda FR-V 2004–2009

1 generation
General information
Number of doors5
CountryJapan
Steering wheel positionLeft
Car classM
At a glance
Engine1668 cm3 Gasoline
Power123 hp
GearboxManual
OriginJapan
Trim
1.7 AT (125 PS)1.7 MT (125 PS)1.8 AT (140 PS)1.8 MT (140 PS)2.0 AT (150 PS)2.0 MT (150 PS)2.2 CTDi MT (140 hp)2.2 MT (140 PS)

Specifications

Engine
Engine power123 hp
Engine power125 PS
Maximum torque154 N*m
Capacity1668 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4800 RPM
Max power at RPM6300 RPM
Cylinder bore75 mm
Max power (kW)92 kW
Stroke cycle94.4 mm
Compression ratio9.9
Engine codeD17A9
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Max trunk capacity1049 l
Curb weight1395 kg
Clearance150 mm
Ground clearance155 mm
Front track width1550 mm
Front track1555 mm
Back track width1560 mm
Rear track1575 mm
Height1610 mm
Width1810 mm
Full weight1890 kg
Wheel size195/65 R15, 205/55 R16
Wheelbase2680 mm
Trailer load (with brakes)3390 kg
Length4285 mm
Min trunk capacity439 l
Payload524 kg
Number of seater6
Pitch Circle DiameterDIA64.1 5x114.3 mm
Body typeMinivan
Gearbox and handling
Turning circle11.2 m
Number of gear5
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)12.3 s
Max speed182 km/h
Fuel tank capacity58 l
Highway driving fuel consumption per 100 km6.5 l
Mixed driving fuel consumption per 100 km7.5 l
City driving fuel consumption per 100 km9.3 l
Fuel95
Emission standardsEURO IV
Cruising rangefrom 620 to 890 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
