Honda Rafaga 1993–1997

1 generation

General information

Number of doors4

Car classC

CountryJapan

Steering wheel positionRight

At a glance

Engine1996 cm3 Gasoline

Power158 hp

GearboxManual

Origin

Japan

Trim

2.0 AT (160 PS)2.0 MT (160 PS)2.5 AT (180 hp)2.5 MT (180 hp)

Specifications

Engine

Max power (kW)118 kW

Engine power158 hp

Engine power160 PS

Maximum torque186 N*m

Capacity1996 cm3

Valves per cylinder4

Turnover of maximum torque4000 RPM

Number of cylinders5

Max power at RPM6700 RPM

Stroke cycle75.6 mm

Cylinder bore82.0 mm

Compression ratio9.3

Injection typedistributed injection (multipoint)

Engine placementFront, transverse

Engine codeG20A

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltSOHC

Bodywork

Curb weight1300 kg

Height1425 mm

Front track1465 mm

Rear track1465 mm

Front track width1465 mm

Back track width1465 mm

Ground clearance155 mm

Clearance155 mm

Width1695 mm

Wheel size185/70 R14, 195/65 R14, 205/55 R15

Wheelbase2770 mm

Length4555 mm

Number of seater5

Pitch Circle DiameterDIA64.1 4x114.3 mm

Body typeSedan

Gearbox and handling

Turning circle11 m

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Fuel tank capacity65 l

Fuel92

Mixed driving fuel consumption per 100 km9.2 l

Acceleration (0-100 km/h)9.7 s

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
