Honda Shuttle 1994–2000

1 generation

General information

Number of doors5

CountryJapan

Steering wheel positionLeft

Car classM

At a glance

Engine2156 cm3 Gasoline

Power148 hp

GearboxAutomatic

Origin

Japan

Trim

2.2 AT (150 PS)2.2 AT AWD (150 PS)2.3 AT (150 PS)2.3 AT AWD (150 PS)

Specifications

Engine

Max power (kW)110 kW

Engine power148 hp

Engine power150 PS

Maximum torque198 N*m

Capacity2156 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque5000 RPM

Max power at RPM5900 RPM

Cylinder bore85 mm

Stroke cycle95 mm

Compression ratio9.8

Injection typedistributed injection (multipoint)

Engine codeF22Z2

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltOHC

Bodywork

Max trunk capacity1237 l

Curb weight1465 kg

Front track1525 mm

Rear track1545 mm

Clearance155 mm

Back track width1555 mm

Front track width1560 mm

Height1630 mm

Ground clearance170 mm

Width1795 mm

Wheel size205/65 R15

Full weight2170 kg

Wheelbase2830 mm

Min trunk capacity290 l

Trailer load (with brakes)3370 kg

Length4770 mm

Number of seater7

Payload705 kg

Pitch Circle DiameterDIA64.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Turning circle11.4 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Mixed driving fuel consumption per 100 km10.0 l

City driving fuel consumption per 100 km11.2 l

Acceleration (0-100 km/h)12.1 s

Max speed183 km/h

Fuel tank capacity65 l

Highway driving fuel consumption per 100 km9.0 l

Fuel95

Suspension and brakes

Front brakesDisc

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
