Hyundai Elantra 2015–2019

AD
No photos yet1.6 AT (128 PS)
General information
Number of doors4
Car classC
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1591 cm3 Gasoline
Power126 hp
GearboxAutomatic
OriginSouth Korea
Series
GT hatchbackSedan
Trim
1.4 AMT (130 hp)1.6 AMT (201 hp)1.6 AT (128 PS)1.6 MT (128 PS)1.6 MT (201 hp)2.0 AT (150 PS)2.0 MT (150 PS)

Specifications

Engine
Compression ratio10.5
Engine power126 hp
Engine power128 PS
Maximum torque155 N*m
Capacity1591 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4850 RPM
Max power at RPM6300 RPM
Cylinder bore77.0 mm
Stroke cycle85.4 mm
Max power (kW)94 kW
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine modelG4FG
Engine codeG4FG
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1325 kg
Clearance135 mm
Height1450 mm
Ground clearance150 mm
Front track1563 mm
Front track width1563 mm
Rear track1572 mm
Back track width1572 mm
Width1800 mm
Full weight1800 kg
Wheel size195/65 R15, 205/55 R16
Wheelbase2700 mm
Trailer load (with brakes)3000 kg
Length4570 mm
Min trunk capacity458 l
Max trunk capacity458 l
Payload475 kg
Number of seater5
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeSedan
Gearbox and handling
Number of gear6
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)11.6 s
CO2 emissions153 g/km
Max speed195 km/h
Fuel tank capacity50 l
Highway driving fuel consumption per 100 km5.4 l
Mixed driving fuel consumption per 100 km6.9 l
City driving fuel consumption per 100 km9.4 l
Fuel95
Emission standardsEuro 5
Cruising rangefrom 530 to 930 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionSemi-dependent, spring
Front brakesventilated disc
