Hyundai Elantra 2003–2010

XD [restyling]
No photos yet1.6 AT (105 PS)
General information
Number of doors4
Car classC
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1599 cm3 Gasoline
Power103 hp
GearboxAutomatic
OriginSouth Korea
Series
HatchbackSedan
Trim
1.6 AT (105 PS)1.6 AT (107 PS)1.6 MT (105 PS)1.6 MT (107 PS)1.8 AT (132 PS)1.8 MT (132 PS)2.0 AT (139 PS)2.0 AT (141 hp)2.0 AT (143 PS)2.0 CRDi MT (111 hp)2.0 MT (113 PS)2.0 MT (139 PS)2.0 MT (141 hp)2.0 MT (143 PS)

Specifications

Engine
Compression ratio10
Engine power103 hp
Engine power105 PS
Maximum torque146 N*m
Capacity1599 cm3
Turnover of maximum torque3000 RPM
Number of cylinders4
Valves per cylinder4
Max power at RPM5800 RPM
Cylinder bore77 mm
Max power (kW)77 kW
Stroke cycle85.4 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine codeG4ED
Engine modelG4ED
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1178 kg
Height1425 mm
Rear track1475 mm
Back track width1475 mm
Front track1485 mm
Front track width1485 mm
Clearance160 mm
Ground clearance168 mm
Width1720 mm
Full weight1740 kg
Wheel size185/65 R15, 195/60 R15
Wheelbase2610 mm
Max trunk capacity415 l
Min trunk capacity415 l
Length4495 mm
Number of seater5
Payload602 kg
Pitch Circle DiameterDIA67.1 4x114.3 mm
Body typeSedan
Gearbox and handling
Turning circle10.2 m
Number of gear4
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
City driving fuel consumption per 100 km10.9 l
Acceleration (0-100 km/h)13.0 s
Max speed170 km/h
Fuel tank capacity55 l
Highway driving fuel consumption per 100 km6.2 l
Mixed driving fuel consumption per 100 km7.8 l
Fuel92
Emission standardsEuro 4
Cruising rangefrom 490 to 870 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
