Hyundai ix35 2010–2013

1 generation
No photos yet2.0 CRDi AT 4WD (184 PS)
General information
Number of doors5
Car classC
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1995 cm3 Diesel
Power181 hp
GearboxAutomatic
OriginSouth Korea
Trim
2.0 AT (136 hp)2.0 AT 2WD (150 hp)2.0 AT 2WD (166 hp)2.0 AT 4WD (150 PS)2.0 CRDi AT 2WD (184 hp)2.0 CRDi AT 4WD (184 PS)2.0 CRDi MT 2WD (184 hp)2.0 CRDi MT 4WD (136 hp)2.0 CRDi MT 4WD (184 hp)2.0 MT (150 PS)2.0 MT (163 hp)2.0 MT 2WD (150 hp)2.0 MT 4WD (150 PS)2.4 AT (178 hp)2.4 MT AWD (177 hp)

Specifications

Engine
Max power (kW)135 kW
Compression ratio16
Engine power181 hp
Engine power184 PS
Capacity1995 cm3
Turnover of maximum torque2500 RPM
Maximum torque392 N*m
Number of cylinders4
Valves per cylinder4
Max power at RPM4000 RPM
Cylinder bore84.0 mm
Stroke cycle90.0 mm
Injection typeCommon rail (diesel)
Engine modelD4HA
Engine codeD4HA
Engine typeDiesel
Timing beltDOHC
Engine placementFront, transverse
Cylinder layoutinline
Presence of intercoolerPresent
Boost typeTurbocharged
Bodywork
Max trunk capacity1436 l
Curb weight1525 kg
Front track1591 mm
Front track width1591 mm
Rear track1592 mm
Back track width1592 mm
Height1660 mm
Ground clearance170 mm
Clearance170 mm
Width1820 mm
Full weight2140 kg
Wheel size215/70 R16, 225/55 R18, 225/60 R17
Wheelbase2640 mm
Length4410 mm
Number of seater5
Payload539 kg
Min trunk capacity591 l
Body typeCrossover
Pitch Circle DiameterDIA67.1 5x114.3 mm
Gearbox and handling
Turning circle10.6 m
Number of gear6
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Acceleration (0-100 km/h)10.1 s
CO2 emissions147 g/km
Max speed195 km/h
Fuel tank capacity58 l
Highway driving fuel consumption per 100 km6.0 l
Mixed driving fuel consumption per 100 km7.1 l
City driving fuel consumption per 100 km9.1 l
Fueldiesel
Emission standardsEURO IV
Cruising rangefrom 640 to 970 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
