Hyundai Santa Fe 2023–2026

5 generation (MX5)

General information

Number of doors5

Car classD

Steering wheel positionLeft

CountrySouth Korea

At a glance

Engine1598 cm3 Gasoline

Power180 hp

GearboxAutomatic

Origin

South Korea

Trim

1.6 AT (235 PS)1.6 AT 4WD (180 hp)1.6 AT 4WD (235 PS)1.6 AT 4WD (265 PS)2.0 AT (247 PS)2.0 AT 4WD (247 PS)2.0 AT AWD (247 PS)2.5 AMT (281 hp)2.5 AMT 4WD (281 PS)2.5 AMT AWD (281 hp)2.5 AT 4WD (194 PS)2.5 AT AWD (194 PS)

Specifications

Engine

Compression ratio10.5

Max power (kW)132 kW

Turnover of maximum torque1500 RPM

Capacity1598 cm3

Engine power179 PS

Engine power180 hp

Maximum torque265 N*m

Number of cylinders4

Valves per cylinder4

Max power at RPM5500 RPM

Cylinder bore75.6 mm

Stroke cycle89.0 mm

Injection typedirect injection (direct)

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Max trunk capacity1275 l

Front track width1646 mm

Back track width1656 mm

Height1730 mm

Width1900 mm

Wheel size235/60/R18

Wheelbase2815 mm

Length4830 mm

Number of seater5, 6, 7

Min trunk capacity725 l

Body typeCrossover

Gearbox and handling

Number of gear6

Gearbox typeAutomatic

Drive wheelsfull

Operating characteristics

Max speed190 km/h

Fuel tank capacity67 l

Fuel95

Acceleration (0-100 km/h)9.5 s

Emission standardsEuro 6

Suspension and brakes

Rear brakesDisc

Front brakesDisc ventilated

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Accumulator battery

Battery capacity1.49 KW⋅h
