Hyundai Trajet 2004–2008

1 generation [restyling] (FO)
General information
Number of doors5
Steering wheel positionLeft
Car classM
CountrySouth Korea
At a glance
Engine1975 cm3 Gasoline
Power138 hp
GearboxAutomatic
OriginSouth Korea
Trim
2.0 AT (112 hp)2.0 AT (137 PS)2.0 AT (140 PS)2.0 CRDi AT (113 hp)2.0 CRDi MT (113 hp)2.0 MT (112 hp)2.0 MT (140 PS)2.7 AT (173 hp)2.7 AT (179 PS)

Specifications

Engine
Compression ratio10.1
Max power (kW)103 kW
Engine power138 hp
Engine power140 PS
Maximum torque186 N*m
Capacity1975 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4500 RPM
Max power at RPM6000 RPM
Cylinder bore82 mm
Stroke cycle93.5 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine codeG4GC
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Front track width1560 mm
Back track width1560 mm
Front track1565 mm
Rear track1565 mm
Ground clearance160 mm
Clearance160 mm
Height1760 mm
Curb weight1771 kg
Width1839 mm
Wheel size215/65 R15
Full weight2440 kg
Max trunk capacity2716 l
Wheelbase2830 mm
Min trunk capacity304 l
Length4699 mm
Number of seater5, 7
Payload639 kg
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeMinivan
Gearbox and handling
Turning circle12.8 m
Number of gear4
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
City driving fuel consumption per 100 km12.9 l
Acceleration (0-100 km/h)13.1 s
Max speed179 km/h
Fuel tank capacity65 l
Highway driving fuel consumption per 100 km7.6 l
Fuel92
Mixed driving fuel consumption per 100 km9.6 l
Emission standardsEURO IV
Cruising rangefrom 500 to 860 km
Suspension and brakes
Front brakesDisc
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
