Hyundai Tucson 2009–2015
2 generationNo photos yet2.0 AT AWD (164 hp)
General information
Number of doors5
Car classC
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1998 cm3 Gasoline
Power164 hp
GearboxAutomatic
Origin
South Korea
South KoreaTrim
2.0 AT 2WD (164 hp)2.0 AT AWD (164 hp)2.0 CRDi AT 2WD (150 hp)2.0 CRDi AT 2WD (184 hp)2.0 CRDi AT AWD (136 PS)2.0 CRDi AT AWD (150 PS)2.0 CRDi AT AWD (184 PS)2.0 CRDi MT 2WD (150 PS)2.0 CRDi MT AWD (136 hp)2.0 CRDi MT AWD (150 hp)2.0 CRDi MT AWD (184 PS)2.0 MT AWD (164 hp)2.4 AT 2WD (176 hp)2.4 AT 2WD (182 PS)2.4 AT AWD (176 hp)2.4 AT AWD (182 hp)2.4 MT 2WD (176 hp)
Specifications
Engine
Compression ratio10.5
Max power (kW)121 kW
Engine power164 hp
Engine power165 PS
Capacity1998 cm3
Maximum torque205 N*m
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM6200 RPM
Cylinder bore86 mm
Stroke cycle86 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine modelG4KD
Engine codeG4KD
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1530 kg
Max trunk capacity1580 l
Front track width1585 mm
Back track width1586 mm
Front track1591 mm
Rear track1592 mm
Height1655 mm
Ground clearance170 mm
Width1820 mm
Clearance195 mm
Full weight2040 kg
Wheel size225/60 R17
Wheelbase2640 mm
Trailer load (with brakes)2947 kg
Length4410 mm
Number of seater5
Payload551 kg
Min trunk capacity728 l
Body typeCrossover
Pitch Circle DiameterDIA67.1 5x114.3 mm
Gearbox and handling
Turning circle10.6 m
Number of gear6
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Mixed driving fuel consumption per 100 km10.2 l
Acceleration (0-100 km/h)10.5 s
City driving fuel consumption per 100 km11.2 l
Max speed182 km/h
Fuel tank capacity58 l
Fuel92
Highway driving fuel consumption per 100 km9.4 l
Emission standardsEURO IV
Cruising rangefrom 470 to 740 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
