Isuzu TF (Pickup) 1988–2002

1 generation

No photos yet2.2 AT (87 PS)

General information

Number of doors2

Car classJ

CountryJapan

Steering wheel positionLeft

At a glance

Engine2238 cm3 Diesel

Power86 hp

GearboxAutomatic

Origin

Japan

Series

Pickup Double cabin Crew Cab Pickup One-and-a-half cabin Space Cab Pickup Single cabin Signle Cab

Trim

2.2 AT (87 PS)2.2 MT (87 PS)2.3 AT (110 PS)2.3 MT (110 PS)2.6 AT (120 PS)2.6 MT (120 PS)2.8 AT (110 PS)2.8 MT (110 PS)3.0 AT (145 PS)3.0 MT (145 PS)

Specifications

Engine

Maximum torque183 N*m

Valves per cylinder2

Compression ratio21

Capacity2238 cm3

Number of cylinders4

Max power at RPM4000 RPM

Turnover of maximum torque4000 RPM

Max power (kW)64 kW

Engine power86 hp

Engine power87 PS

Cylinder bore88 mm

Stroke cycle92 mm

Engine modelc223t

Engine codeC223-T

Engine typeDiesel

Engine placementFront, longitudinal

Injection typeHPFP (Diesel)

Cylinder layoutinline

Timing beltOHV

Boost typeTurbocharged

Bodywork

Height1600 mm

Curb weight1650 kg

Width1690 mm

Number of seater2

Clearance205 mm

Wheel size215/75 R15

Wheelbase2680 mm

Length4425 mm

Body typePickup

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

Mixed driving fuel consumption per 100 km10.0 l

Fuel tank capacity80 l

Fueldiesel

Suspension and brakes

Back suspensionDependent, spring

Front brakesDisc

Rear brakesdrum

Front suspensionIndependent, Torsion

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
