Isuzu Wizard 1998–2004

2 generation

No photos yet3.0 AT 4WD (145 PS)

General information

Number of doors5

Car classJ

CountryJapan

Steering wheel positionLeft/Right

At a glance

Engine2999 cm3 Diesel

Power143 hp

GearboxAutomatic

Origin

Japan

Trim

3.0 AT 4WD (145 PS)3.0 MT 4WD (145 PS)3.2 AT 4WD (215 PS)3.2 MT 4WD (215 PS)

Specifications

Engine

Stroke cycle104.9 mm

Max power (kW)107 kW

Engine power143 hp

Engine power145 PS

Compression ratio19

Turnover of maximum torque2000 RPM

Maximum torque294 N*m

Capacity2999 cm3

Number of cylinders4

Valves per cylinder4

Max power at RPM4100 RPM

Engine model4jx1

Engine code4JX1

Cylinder bore95.4 mm

Engine typeDiesel

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, longitudinal

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Height1135 mm

Front track width1515 mm

Back track width1520 mm

Curb weight1770 kg

Width1815 mm

Clearance205 mm

Wheel size225/80 R15, 245/70 R16

Wheelbase2460 mm

Length4250 mm

Number of seater5

Body typeCrossover

Pitch Circle DiameterDIA100.1 6x139.7 mm

Gearbox and handling

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Acceleration (0-100 km/h)14.1 s

Max speed161 km/h

Fuel tank capacity67 l

Fueldiesel

Suspension and brakes

Back suspensionDependent, spring

Front suspensionIndependent, Torsion

Front brakesventilated disc

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
