Jeep Liberty (Patriot) 2006–2016

1 generation
No photos yet2.4 CVT 4WD (170 PS)
General information
Number of doors5
Car classC
Steering wheel positionLeft
CountryUSA
At a glance
Engine2360 cm3 Gasoline
Power168 hp
GearboxContinuously variable transmission (CVT)
OriginUnited States
Trim
2.0 CVT (158 hp)2.0 CVT 4WD (158 PS)2.0 MT (140 PS)2.0 MT (158 PS)2.0 MT 4WD (140 PS)2.0 MT 4WD (158 PS)2.1 MT 4WD (163 PS)2.4 AT (174 hp)2.4 AT 4WD (174 PS)2.4 CVT (174 hp)2.4 CVT 4WD (170 PS)2.4 CVT 4WD (174 PS)2.4 CVT AWD (170 PS)2.4 MT 4WD (174 PS)

Specifications

Engine
Compression ratio10.5
Max power (kW)125 kW
Engine power168 hp
Engine power170 PS
Maximum torque220 N*m
Capacity2360 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4500 RPM
Max power at RPM6000 RPM
Cylinder bore81.0 mm
Stroke cycle95.5 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine codeERZ
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Max trunk capacity1357 l
Front track width1520 mm
Back track width1520 mm
Curb weight1525 kg
Height1667 mm
Width1808 mm
Clearance201 mm
Full weight2010 kg
Wheel size235/60 R18, 235/65 R17, 235/70 R16
Wheelbase2635 mm
Min trunk capacity328 l
Length4424 mm
Number of seater5
Body typeCrossover
Pitch Circle DiameterDIA71.6 5x114.3 mm
Gearbox and handling
Drive wheelsAll wheel drive (AWD)
Gearbox typeContinuously variable transmission (CVT)
Operating characteristics
Acceleration (0-100 km/h)11.3 s
City driving fuel consumption per 100 km11.6 l
Max speed185 km/h
CO2 emissions216 g/km
Fuel tank capacity51 l
Highway driving fuel consumption per 100 km7.6 l
Mixed driving fuel consumption per 100 km9.1 l
Fuel95
Emission standardsEuro 4
Suspension and brakes
Front brakesDisc
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
