Jeep Compass 2017–2021

2 generation (MP / 552)

At a glance

Engine1368 cm3 Gasoline

Power170 hp

GearboxAutomatic

OriginN/A

Trim

1.4 4x4 AT (170 hp)1.4 MT (140 hp)1.6 MT (120 hp)2.0 4x4 AT (140 hp)2.0 4x4 MT (140 hp)2.4 4x4 AT (150 hp)2.4 4x4 AT (175 hp)2.4 4x4 AT (182 hp)2.4 4x4 MT (182 hp)2.4 AT (182 hp)2.4 AT AWD (150 PS)2.4 AT AWD (175 PS)2.4 MT (182 hp)

Specifications

Engine

Max power (kW)127 kW

Capacity1368 cm3

Engine power170 hp

Engine power173 PS

Maximum torque250 N*m

Number of cylinders4

Valves per cylinder4

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 2 500 RPM

Max power at RPMto 5 500 RPM

Boost typeTurbo

Bodywork

Front track1542 mm

Rear track1543 mm

Height1647 mm

Max trunk capacity1693 l

Ground clearance198 mm

Width2033 mm

Wheelbase2636 mm

Length4394 mm

Number of seater5

Min trunk capacity770 l

Body typeCrossover

Gearbox and handling

Turning circle11 m

Number of gear9

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Max speed204 km/h

Highway driving fuel consumption per 100 km5.9 l

Fuel tank capacity60 l

Mixed driving fuel consumption per 100 km6.9 l

City driving fuel consumption per 100 km8.7 l

Fuel92

Acceleration (0-100 km/h)9.3 s

Emission standardsEURO VI

Cruising rangefrom 690 to 1 020 km

Suspension and brakes

Front brakesDisc

Rear brakesDisc

Back suspensionIndependent, Lever, spring

Front suspensionIndependent, McPherson Struts, Stabilizer bar

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
