Kia Rio 2009–2011

2 generation [restyling] (JB)
General information
Number of doors4
Car classB
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1399 cm3 Gasoline
Power95 hp
GearboxAutomatic
OriginSouth Korea
Series
HatchbackSedan
Trim
1.4 AT (95 hp)1.4 AT (97 PS)1.4 MT (95 hp)1.4 MT (97 PS)1.5 CRDi MT (110 hp)1.5 MT (109 hp)1.6 AT (112 hp)1.6 MT (112 hp)

Specifications

Engine
Compression ratio10
Maximum torque125 N*m
Capacity1399 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4700 RPM
Max power at RPM6000 RPM
Max power (kW)71 kW
Cylinder bore75.5 mm
Stroke cycle78.1 mm
Engine power95 hp
Engine power97 PS
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine codeG4EE
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1080 kg
Rear track1460 mm
Back track width1460 mm
Height1470 mm
Front track1470 mm
Front track width1470 mm
Ground clearance155 mm
Clearance155 mm
Full weight1580 kg
Width1695 mm
Wheel size175/70 R14, 195/55 R15, 185/65 R14
Wheelbase2500 mm
Min trunk capacity390 l
Max trunk capacity390 l
Length4250 mm
Number of seater5
Payload500 kg
Pitch Circle DiameterDIA54.1 4x100 mm
Body typeSedan
Gearbox and handling
Turning circle10 m
Number of gear4
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)14.5 s
Max speed168 km/h
Fuel tank capacity45 l
Highway driving fuel consumption per 100 km5.4 l
Mixed driving fuel consumption per 100 km6.9 l
Fuel95
City driving fuel consumption per 100 km9.5 l
Emission standardsEURO IV
Cruising rangefrom 470 to 830 km
Suspension and brakes
Rear brakesdrum
Front suspensionIndependent, spring
Back suspensionSemi-independent, torsion
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
